Liquid Filled: Glycerine(default) / Silicon oil
Wetted Part: Brass + Phosphor bronze
Body: SS304
Connection Type: 2 Parts
Protection: IP68
Pressure Range: VAC~0.6bar~1000bar
Accuracy: 1.0%
101 &102 series are filled with glycerine oil, which are used to resist vibration and pulsation, these gauges are suited to a broad range of plant, process,hydraulic and fluid power applications.
Specification | Case | SS304, Polished |
Ring | SS304, Polished | |
Window | 101:Polycarbonate 102:Tempered Glass | |
Dial | Aluminum | |
Pointer | Aluminum | |
Connection | Brass | |
Movement | Brass | |
Bourdon tube | Phosphorus Bronze | |
Thread size | 1/8'’,1/4'’,3/8'’,1/2'’ | |
Accuracy | 1.6%/1.0%*(*available) | |
Pressure range | VAC~9PSI~15000PSI |
